Long Description
- Wide design provides the drive-thru clearance for greater under vehicle access and less obstruction for service to battery electric vehicles
- Standard with adjustable TA truck and RA round poly adapters for use on framed and unibody vehicles. Includes (4 each) 3 1/2” and 5” adapter extensions plus storage rack
- Rise height of over 75”
- Original “Double S” column
- Available with SHOCKWAVETM power
- ALI Gold Certified
Rise
75 3/4” - 78 1/8”
Overall Height
13’ 8” STANDARD
Overall Width
11’ 5 5/8” to 12’ 5 5/8”
Drive-thru
102 3/8” to 114 3/8”
Inside Columns
114 7/8” to 126 7/8”
Arm Reach Min/Max
27 1/2” / 59”
Min. Adapter Height
3 7/8”
Min. Bay Size
12’ x 26’
Min. Ceiling Height
13’ 9” STANDARD
Motor / Voltage 1Ø
2 HP, 208-230V
Time of Full Rise
60 seconds
